Using galvanized steel wires and PVC coated iron wires as raw material, the barbed wire provides a higher than normal level of tensile strength and corrosion resistance in comparison to commonly-used anti-climb systems. A wide application of fencing topping is found in grass boundary, railway, highway, car parks, industrial premises, animal husbandry and just to name a few.
Note: The wire colors are available in blue, green, yellow and more.
Technical Parameters of Barbed Wire| Barbed Wire Specification | ||||
| Type | Wire Gauge (SWG) | Barb Distance (cm) | Barb Length (cm) | |
| Electric Galvanized Barbed Wire; Hot-dip zinc plating barbed wire | 10# x 12# | 7.5-15 | 1.5-3 | |
| 12# x 12# | ||||
| 12# x 14# | ||||
| 14# x 14# | ||||
| 14# x 16# | ||||
| 16# x 16# | ||||
| 16# x 18# | ||||
| PVC coated barbed wire; PE barbed wire | before coating | after coating | 7.5-15 | 1.5-3 |
| 1.0mm-3.5mm | 1.4mm-4.0mm | |||
| BWG11#-20# | BWG8#-17# | |||
| SWG11#-20# | SWG8#-17# | |||
| PVC PE coating thickness:0.4mm-0.6mm; different colors or length are available at customers request | ||||
Packing
With wooden spool* on pallet, or Rolled without pallet.
*(A hole was bored in the Wooden spool's center, allowing retailers to slip spools onto a horizontal bar for easy unrolling.)
